- Functional Description
- Specifications
- Applications
1. Integrated buckle-connected without joint connector , drag-proof design
2. water-proof design with high-conductivity glue
3. Heat-radiation design with low heat-resistance path
4. Good endurance and low-voltage and constant current design
5. Soft characteristic of product and multiple installation method
技術分類Technical?Classification | 項目規格 Item | 參數 Parameter |
電氣性能Electrical?Properties | 供電電壓 Input?voltage | DC24V |
最大功耗 Max.power?consumption | 3W | |
光學性能Optical?Properties | 光源組成 LED?composition | 36顆LED 36pcs?LED |
光色 LED?color | RGB/白色/黃色/藍色 RGB／White／Yellow／Blue | |
光通量 Luminous?Flux | 150lm | |
光束角 Beam?angle | 180° | |
亮度等級 Brightness?grade | 每種顏色256?級 256?grade?percolor | |
光通維持率 Luminous?maintenance?rate | 50000?hour（@80%） | |
控制方式 Control?Mode | 控制接口 Interface | DMX512? |
控制系統 Control?System | 中鳴科技 Easyplay5.0（joinmax） | |
結構性能Structure | 尺寸(長x寬x高)?Dimension(LxWxH) | 100×100×56mm |
重量 Weight | 0.2Kg | |
燈體材料 Material | 壓鑄鋁（表面處理噴砂、噴涂）電鍍可選） Die?casting?aluminum | |
表面顏色 Surface?color | 白色 White | |
燈具連接 Connection | 公母接頭 Male?and?female?connectors | |
防護等級 IP?grade | IP66 | |
工作溫度 Work?temperature | -20℃～50℃ | |
工作濕度 Work?humidity | 0～90% | |
使用環境 Work?Environment | -20℃～40℃ | |
安全性能Safety | 認證 Certificate |
供電方式 Input?Voltage | 發光顏色 LED?Color | 產品編號 Parameter |
DC24V | RGB?PH5?36顆3W RGB?PH5?36pcs?3W | JZ02-103608-011 |
白光PH5?36顆3W? White?PH5?36pcs?3W | JZ02-103607-011 | |
黃光PH536顆3w? Yellow?PH5?36pcs?3W | JZ02-103606-011 | |
藍光PH536顆3W Blue?PH5?36Des?3W | JZ02-103605-011 |
-
