- Functional Description
- Specifications
- Applications
1、3 independent relay output controlled by DALI.
2、The maximum current load of each contact is 10A.
3、Each switch contact assigned with one DALI address輸入電壓范圍 /Input voltage range | 220～240VAC | ? | 執行標準// Standard |
輸入頻率/ Input Frequency | 50/60Hz | ? | IEC 62386-101(DALI協議標準) |
功率/ Power | <2W（Max） | ? | IEC 62386-102(DALI協議標準) |
輸出繼電器觸點額定電流 / Output relay contacts rated current | 10A | ? | ? |
環境溫度 / Ambient temperature | 0～50℃ | ? | ? |
儲存溫度 / Storage Temperature | -20～70℃ | ? | ? |
濕度/ Humidity | 5%～85% | ? | ? |
保護等級 / Protection class | IP20 | ? | ? |
-
